9V battery size and other names
A 9V alkaline battery is a rectangular block up to 48.5 mm tall, 26.5 mm wide and 17.5 mm deep (1.91 × 1.04 × 0.69 in), with both snap terminals on top. Energizer's 522 weighs about 45 g.[1 · Oct 29, 2026]
| Nominal voltage | 9.0 V[1 · Oct 29, 2026] |
|---|---|
| Height | 46.4 to 48.5 mm[1 · Oct 29, 2026] |
| Width × depth | 24.5 to 26.5 mm × 15.5 to 17.5 mm[1 · Oct 29, 2026] |
| Standard names | ANSI 1604A; IEC 6LR61 or 6LF22[1 · Oct 29, 2026] |
| Also labeled as | 522, A522, L522, MN1604, A1604[2 · Oct 29, 2026] |
| Shelf life (Energizer 522) | 5 years[1 · Oct 29, 2026] |
9V batteries in smoke alarms
- Some alarms run on a 9V; Kidde's i9050, for example, is powered by one.[3 · Oct 29, 2026] Others use AA batteries or a sealed 10-year battery, so check the label on the back of the alarm or its manual.[4 · Oct 29, 2026][5 · Oct 29, 2026]
- Kidde says off-brand or old batteries can put an alarm into low-battery mode.[4 · Oct 29, 2026]
- Replace the battery at least once a year, and right away if the alarm chirps.[5 · Oct 29, 2026][6 · Oct 29, 2026] More in the smoke alarm battery guide.
Storing and tossing 9Vs
Both terminals sit side by side on top, so a loose 9V can touch keys or coins. Energizer warns against carrying batteries loose in a pocket with coins, which can short them and make them heat up.[2 · Oct 29, 2026] For recycling, the EPA and The Battery Network suggest bagging batteries or covering the terminals with non-conductive tape.[7 · Oct 29, 2026][8 · Oct 29, 2026]
